• Class 3 LED Surge Protection Device EN61643-11 Standard 35mm Din rail
Class 3 LED Surge Protection Device EN61643-11 Standard 35mm Din rail

Class 3 LED Surge Protection Device EN61643-11 Standard 35mm Din rail

Product Details:

Place of Origin: Dongguan China
Brand Name: Uchi
Certification: CE / SGS / ISO9001
Model Number: LED Surge Protection Device

Payment & Shipping Terms:

Minimum Order Quantity: 100 piece / pieces
Price: Negotiate Ex-work / FOB price
Packaging Details: Export package
Delivery Time: 8-15 days after payment
Payment Terms: TT / LC
Supply Ability: 50000 pieces per month
Get Best Price Contact Now

Detail Information

Brand Name: Uchi Name: LED Surge Protector
Warranty: 3 Years In: 3kA
Nominal A.c.voltage (power Supply) [UN: 230V AC: 275VDC
Material: Thermoplastic UL94-V0 Standard: IEC 61643-11
Classification: Class III Response Time: <25ns
Application: LED Product
High Light:

35mm Din Rail Class 3 Surge Protection


EN61643-11 Standard LED Surge Protection Device


35mm Din Rail LED Surge Protection Device

Product Description

Class 3 LED Surge Protection Device EN61643-11 Standard 35mm Din rail

Standard EN61643-11 3kA LED Light Surge Protection Device For LED Product

Lightning protection

  LED Surge Protection Device
SPD classification according to EN61643-11 Type 3
SPD classification according to IEC 61643-11 Class III
Nominal a.c. voltage Un 230V
Max. continuous operating a.c. voltage Uc 275V
Max. continuous operating d.c. voltage Uc 300V
Nominal discharge current (8/20us) In 3kA
Combined impulse Uoc 6kV
Voltage protection level Up ≤1200V
Response time tA ≤25ns
Operating temperature range Tu -40℃—80℃
Operating state / fault indication LED
For mounting on 35mm Din rail
Enclosure materail Thermal plastic UL94-V0
Degree of protection IP20



Energy saving LED lights used as street lighting is becoming increasingly popular. But their free-standing poles are at risk in two ways: From lightning and from surge voltages via the power supply. For the protection of sensitive electronic drivers and LED lights inside street lamps, Britec has now developed a tailor-made surge arrestor. The type 3 arrestor BR275-6 has a high level of conducting capacity of up to 6 kA. Having a very low protection level of below 1.2 kV, it is also suitable for the protection of very sensitive electronic components. Thanks to its compact design, the housing can be mounted in the pole end area or in the street lamp head.


Main Character:


• Surge Protection Device: 275V AC.
• 3kA nominal discharge current (8/20us).
• Build-in beep status indication.

• Single-phase flexible surge protection

• High discharge capacity, quick response

• Low voltage protection level

• It provides surge protection up to 6Ka.
• EN 61643-11, IEC 61643-11 compliance.
• It is a 3-leaded device.
• BR275-6-L surge arrester is installed between LPZ2 and LPZ3, providing an extra guarantee to the
end user in terms of reliability and durability.



  • Protection class: Type 3, Class III.
  • High performance varistor with thermal disconnection tripping device.
  • Nominal AC Voltage, 230V.
  • Nominal Discharge current: 5kA.
  • Rated to IP20.
  • Surge protectors are used to guard sensitive equipments from voltage spike.
  • Used in surge protectors, thermally protected varistor modules from Britec are built with high-quality, dependable materials.
  • LED Lights Surge Protection Device for LED Street Lights can be connected in series or parallel.
• Provide an additional level of surge and transient protection in industrial and commercial applications.
• Suit for the outdoor luminaires such as street lights, flood lights etc.

Class 3 LED Surge Protection Device EN61643-11 Standard 35mm Din rail 0
