• 5KA Led Driver Surge Protector Combined Impulse 10ka Single Phase
5KA Led Driver Surge Protector Combined Impulse 10ka Single Phase

5KA Led Driver Surge Protector Combined Impulse 10ka Single Phase

Product Details:

Place of Origin: Dongguan China
Brand Name: Uchi
Certification: CE / SGS / ISO9001
Model Number: LED Surge Protection Device

Payment & Shipping Terms:

Minimum Order Quantity: 100 piece / pieces
Price: Negotiate Ex-work / FOB price
Packaging Details: Export package
Delivery Time: 8-15 days after payment
Payment Terms: TT / LC
Supply Ability: 50000 pieces per month
Get Best Price Contact Now

Detail Information

Brand Name: Uchi Name: LED Surge Protector
Warranty: 3 Years Type: Class III
Nominal A.c.voltage (power Supply) [UN: 230V Material: Thermoplastic UL94-V0
Application: Applied For Street Lights LED Driver. Color: Light Gray
High Light:

5KA surge protection device single phase


5KA led driver surge protector


10ka led driver surge protector

Product Description

5KA Led Driver Surge Protector Combined Impulse 10ka Single Phase

5kA LED Surge Protection Device , 10kA Surge Protector With Parallel Connection

Lightning protection


  LED Surge Protection Device
SPD classification according to EN61643-11 Type 3
SPD classification according to IEC 61643-11 Class III
Nominal a.c. voltage                                                  Un 230V
Max. continuous operating a.c. voltage                     Uc 275V
Max. continuous operating d.c. voltage                     Uc 300V
Nominal discharge current (8/20us)                            In 5kA
Combined impulse                                                   Uoc 10kV
Voltage protection level                                              Up ≤1. 0kV
Response time                                                            tA ≤25ns
Operating temperature range                                     Tu -40°C~ +80°C
Operating state / fault indication LED
Enclosure materail                    Thermal plastic UL94-V0
Degree of protection IP20




Used for LED power source fine protection. Can be soldered with parallel connection on to the PCB (Printed Circuit Board) or onto the external power source of electronic equipment to protect from power surges. Designed according to IEC 61643-11 / EN 61643-11 / GB 18802.1 standard, applied in SPD class III (Class D) for fine protection of electronic equipment. LED drivers etc.


Main Character:


• Single-phase flexible surge protection

• High discharge capacity, quick response

• Low voltage protection level

• IP67 water resistant



  • Protection class: Type 3, Class III.
  • High performance varistor with thermal disconnection tripping device.
  • Nominal AC Voltage, 230V.
  • Nominal Discharge current: 3kA.
  • Rated to IP20.
  • Surge protectors are used to guard sensitive equipments from voltage spike.
    5KA Led Driver Surge Protector Combined Impulse 10ka Single Phase 0


    Q1: Are you a factory or a trade company?
    A: We are the factory.

    Q2: Where are your products distributed?
    A: Our products are distributed all over the world, Main market are Europe, North America, the United Arab Emirates, Africa and so on.

    Q3: Can I have a sample?
    A: Yes, but according to our company's policy, we provided free samples, while you should pay the freight fee; the sample can be delivered by TNT/DHL/UPS/FEDEX.

    Q4: Which port is the nearest from you?
    A: Guangzhou port or Shenzhen Port or Hong Kong port.

    Q5: What's your lead time?
    A: Sample lead time: 3~5 working days.
    Mass production: usually 10~30days.
    For big orders, honestly, it depends on the order quantity and designs.

    Q6: When can I get the price?
    A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry as priority.

    Q7: Can you do the design for us?
    A: Yes, we have a professional team having rich experience in molding design, electrical system developing and manufacturing. Please just tell us your ideas and we will help you to carry out your ideas into a perfect artwork. You can pay for the molding fee and own the mold by yourself or we can cooperate on the molding.

    Q8: OEM & ODM are accepted or not?
    A: OEM&ODM are welcome.
