• Class 2 12v Dc Surge Protector , 40KA Low Voltage Protection
Class 2 12v Dc Surge Protector , 40KA Low Voltage Protection

Class 2 12v Dc Surge Protector , 40KA Low Voltage Protection

Product Details:

Place of Origin: Dongguan China
Brand Name: Uchi
Certification: CE / SGS / ISO900
Model Number: OBV10-I-50

Payment & Shipping Terms:

Minimum Order Quantity: 50 Piece/Pieces
Price: Negotiate Ex-work / FOB price
Packaging Details: Export package
Delivery Time: Shipped in 10 days after payment
Payment Terms: TT / LC
Supply Ability: 100000 Piece/Pieces Month
Get Best Price Contact Now

Detail Information

Name: Lightning Protection Device Un: 220V DC
Material: PA66 Rated Working Voltage Un (V): 24V-1500V
Max.discharge Current Imax 8/20 (kA): 40KA Protection Class IP: IP 20
IEC Classification: Class II Operating Temperature: -40°C∼+85°C
High Light:

40KA low voltage protection

,

Class 2 12v dc surge protector

,

40KA 12v dc surge protector

Product Description

Class 2 12v Dc Surge Protector , 40KA Low Voltage Protection

Lightning Protection Device Solar PV 40kA Low Voltage DC Surge Protector Device

DC surge protection device (NDU6) used in lightning protection of solar photovotaic power generation system or other DC power supply system and make the system against lightning overvoltage.Built-in temperature control circuit technology,high security;indicator window green means normal,red to represent the fault,must be replaced and legible;optional remote communication interface,the realization of remote monitoring;high flow,high safety and stability. The product can be pluggable modular design,standard guide installation,selection of high-quality photovoltaic professional lightning protection devices,stable performance,built-in hot melt,flow in dual protection circuit,visualization window,normal green,red fault,large flow capacity,low residual voltage,fast response(nanosecond),with remote monitoring function,convenient remote monitoring(optional).



Performance characteristics:


Adopt the latest thermal separation technology, built-in thermal protection, automatic separation device for short-circuit failure, completely avoid fire;
The core components adopt internationally well-known brands, with excellent performance, stable and reliable work;

Lightning current arrestors OBV10-I-50 meet the type 1 requirement class according to IEC 61643-11. These devices protect low-voltage consumer systems from overvoltages of all types and are available in single-pole to four-pole versions.The voltage-limiting,high-performance spark gaps provide several benefits.A short response time, a low protection level and high current leakage capability with long service life.



The main parameters:


Nominal working voltage Un: 12VDC
Maximum working current: 2A
Nominal discharge current In(8/20μs): 5kA
Maximum discharge current Imax (8/20μs): 10kA
Combination method: 1P
Response time: 25ns
Working environment: -40℃~+85℃
Installation method: rail installation



For protecting low voltage equipment from surge damages. Applied in pluggable SPD Class II (Class C) for TN power supply system. Designed according to IEC 61643-1 / GB 18802.1.

Main character:

1. Small volume, high discharge capacity, pluggable

2. Quick response

3. Double thermal disconnector devices, providing reliable protection.

4. Multifunctional terminal for connecting conductors and busbars

5. Green window will change when fault occurs and also provide remote alarm control contact at the same time.



Place of Origin: Dongguan
Qualification certification: CE, FCC, ROHS, product test report, Pacific Product Insurance, etc.
Test standard: IEC 61643-1:2005; GB 18802.1-2011 Low Voltage Surge Protector (SPD) Part 1 Surge Protector for Low Voltage Distribution System-Performance Requirements and Test Methods

Scope of application:
This product is a special lightning surge protector for DC systems, suitable for 12V DC power supply systems.




Model



OBV10-I-50



IEC Classification



Class II



DC Network Un (50/60Hz)(V)



220V DC



Max. continuous operationg voltage Uc (V)



350 DC



Nornimal discharge current In (kA)



20kA



Max. discharge current(8/20us) Imax (kA)



40kA



Voltage protection level Up (kV)



≤1.4kV



Max. backup fuse (A)



35A DC (gG)



Response time tA



≤25ns



Capacity of withstand short circuit



300A



Operating temperature



-40°C∼+85°C



Relative humidity



≤95%(25°C)



Max. cross-sectional area of wire



25mm2 multi-strand cord



Dimensions (1P) (W*L*H) (mm)



18X90X62



Mounting



DIN Rail 35mm



Protection rating



IP 20



Housing material



PBT



Flame retardant rating



UL 94 V-0



Capacity of remote signaling contact



250VAC/0.5A 30VDC/3A



Max.cross-sectional area of wire for remote signaling contact



1.5mm² multi-strand cord/single cord



Status indicator



Normal: Green Malfunction: Red



Standards compliance



EN50539-11 IEC61643-31 GB/T 18802.31



Safety super wide electrical spacing and creepage distance, high voltage withstand voltage,meet high altitude area use requirement.
No load current is considered; plug and pull design, can be charged replacement, easy to maintain.Built-in temperature control circuit technology, high safety performance, no after flow.
Indicates that the green color of the window is normal and any red indicates failure. Clear and easy todistinguish.
Optional remote monitoring interface can be used for remote monitoring.
High working voltages, high pass flow, high safety performance and high stability.
